Animal Operation Surgical Equipment Portable Desktop Anesthesia Machine BAM-5
Professional for Veterinary
Pneumatically and electrically
Portable Anesthesia Machine system
Specifically designed for use with both big and small animal anesthesia ventilators, it can be widely applied in veterinary hospitals, animal research and development institutes, university laboratories, animal clinics, zoos, and more.
Features
1.Compact and save space.
2.Lightweight and easy to move, saving animal hospital costs.
3.Achieve automatic breathing with lPpV mode, ensuring the animal's comfort.
4.Specifically designed for animal use, with both big and small animal bellows.
5.Utilizes high-quality gas sources with no leakage.
6.LED digital display shows important parameters.
7.Easy and simple to operate with a key interface for parameter settings.
8.Built-in battery provides over two hours of continuous operation in case of power failure.
9.Compatible with different brands of veterinary anesthesia machines.
Parameters
Model | BAM-5 |
Working mode | Auto-control , Manual |
Ventilation mode | IPPV , MANUAL |
Bellow | 0-300ml,300-1500ml |
Driving mode | Pneumatically and electrically |
Screen | LED digital display |
Monitor | Tidal volume,breathing rate , l:E,peak pressure |
Tidal volume | 20ml/min-1500ml/min |
Adjustment breathing rate | 4-60bpm |
I:E | 3:1, 2:1, 1.5:1, 1:1, 1:1.5, 1:2, 1:3 |
Minute ventilation volume | No less than18L/min |
Ainway pressure upper limit | 2-6kpa |
Ainway pressure lower limit | 0.6-2kpa |
Alarm | Low oxygen supply pressure alarm,ainway pressure upperlimitalarm,airway pressure lower limit alarm,mute |
Configuration | Main unit, bellows (0-300ml,300-1500ml ), folded bag bellow cover, medical corrugated pipelines, O2 supply hose, power cable, flow sensor,etc |
